Hafele GL5700 Digital Gate Lock Specification
Authentication Methods:
 |
Bluetooth |
 |
PIN code |
 |
Dual Fingerprint (Front & Back) |
 |
RFID tags |
 |
Mechanical key |
 |
Remote Control |
- Manage by 1 master password and 10 user Codes.
- Dual unlocking options – Fingerprint available in Both Front and Back Sides.
- Auto / Manual locking mode is flexible.
- Voice installation guide (English).
- Low-battery warning by sound.
- RFID Tags – 2 no.s (Upto 100)
- Fingerprint User Memory – 40 no.s
Technical Features:
| Out-body Dimension (W x H x D) mm | 77 (w) x 200(H) x 71(D) mm |
|---|---|
| In-body Dimension (W x H x D) mm | 71 (W) x 172 (H) x 13 (D) mm |
| Applicable Door Thickness | 30 – 60mm (Default), 60 – 90 (optional) |
| Door to Gate Allowance | 70mm |
| User Friendly Interface | Yes |
| Intrusion Prevention | Yes |
| Power | 4 pcs AA Alkaline Batteries (not included) (DC 6V) |
| Emergency Power |
5V2A USB TYPE C |
| Battery Life | Approximately 1 Year (Average 10 times per day) |
| Working Temperature | -20 – -60°C |
| Warranty | 3 years [Enroll through Hafele to obtain your 3rd-year warranty] |
